200A Tesla DC Fast Charger Cale-UL Rated NACS Connector

Short Description:

Rated current : 80A 125A 150A 200A,250A

Operating voltage : 1000V DC

Insulation resistance : >2000MΩ

Terminal temperature rise :<50K

Withstand voltage :3200V

Waterproof degree:IP54

Contact impedance:0.5MΩ Max

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Features	1. Meet NACS standard
	2. Concise appearance, support back installation
	3. Back Protection class IP67
	4.Max charging power: 200kW
Mechanical Properties	1. Mechanical life: no-load plug in/pull out＞10000 times
Mechanical Properties	2. Impat of external force: can afford 1m drop amd 2t vehicle run over pressure
Electrical Performance	1. DC input: 200A 1000V DC MAX
	3. UV Resistance:F1 per UL 746C
	4. Insertion / Withdrawal Force: ＜ 90N
	5. Withstand Voltage: 3200V
	6. Contact resistance: 0.5mΩ Max
Applied Materials	1. Case Material: Thermoplastic,flame retardant grade UL94 V-0
Applied Materials	2. Pin: Copper alloy,silver +thermoplastic on the top
Environmental Performance	1. Operating temperature: -40°C~+50°C
