30KW High Efficiency DC Fast Charging Station Use EV Charger Power Module

Short Description:

Overview

Quick Details
Place of Origin:
China
Model Number:
DCM1000100
Type:
DC/AC Inverters
Output Type:
TRIPLE, Multiple
Output Current:
60A
Output Frequency:
50/60Hz
Size:
455*300*94MM(D*W*H)
Weight:
17KG
Certificate:
CE
Product name:
30kW Power Module
Power Supply:
3P+PE
Rated Voltage:
260~470V AC
Max. Input Current:
60A
Input Frequency:
50/60Hz
Standby Power:
<8W
Rated Power:
30kW
Enclosure:
Aluminized Zinc plate (SGLCC)
LED Indicator:
Green/Yellow/Red
Configuration:
Manual/Auto


Product Detail

FAQ

Product Tags

ts Description
1.Multiple Options
Different power options 20KW/30KW Multiple output voltages 500V/750V/1000V
2.Low Energy Consumption
Unique sleep mode, less than 2W power High conversion efficiency up to 96% Intelligent parallel mode, working with the best efficiency
3.High Reliability
Overall temperature monitoring Defenses of moisture, salt spray and fungus MTBF > 100,000 hours Super Adaptability Wide input voltage range 260~470V AC Wide working temperature range -30℃~+50℃

30KW High Efficiency Electric Vehicle DC Fast Charging Station Use EV Charger Power Module

rectifier module is an adjustable ACDC module with AC voltage input and DC voltage output. The module adopts liquid cooling
cooling technology, high level of protection (IP50), good heat dissipation performance, suitable for harsh environments. The
module adopts DSP digital control, resonance soft switch, active PFC technology, and multiple patent protection; the module has
high power density, high power factor, small harmonic, high efficiency, and multi-module parallel performance.

2. Main Features
* High protection level

Protection Level IP50, is especially suitable for harsh environments.
* High efficiency

Reduce energy consumption and loss, meet the requirements of energy conservation and emission reduction, and save electricity
bills for customers.
* High power density

Save customer space and reduce system costs.
* DSP Digital Control

Less devices, higher environmental stability, higher reliability, and more convenient capacity expansion.
* Low-input harmonics

Reduce pollution to the power grid, and have a higher power grid adaptability.
* Wide input voltage range, wide output voltage range

Suitable for most different input and output voltage situations.
* Wide operating temperature range

Wide working temperature range satisfies most harsh working environments
* Hot-plug

Suitable for easy use and reduce maintenance costs.
* Built-in anti-anti protection, with failure self-isolation function

Highly improve the system reliability.
* Perfect fault self-detection tips

Rich fault detection, convenient for customer maintenance.

REG1K0100G-1
