EV Products
-
Electric car cord hose reel retractable ev cable reel for electric vehicle charging
Roll compact EV cord reel spring retractable cable reel electric automatic ev charging reel drum box
vehicle charging reel is suitable for single phase electrical connections and is delivered ready fitted with cables, plugs & mounting bracket as shown. -
coil type charging guns for cable reel charger 32A 1P 7meter
Roll compact EV cord reel spring retractable cable reel electric automatic ev charging reel drum box
vehicle charging reel is suitable for single phase electrical connections and is delivered ready fitted with cables, plugs & mounting bracket as shown. -
15KW EV charger module used for CCS2 and CHAdeMO EV charger
15KW 750V Charger Power Module:Main Feature:*Inside high frequency transformer isolation*Full hot plug design*High efficiency over the full load range, full load efficiency higher than 95.5%*Wide output voltage range, 150-750Vdc, suitable for a wide range of EVs*Constant current for higher output power at low output voltage*An internal patented intelligent discharge circuit automatically discharges residual charge, simplifying system designs*Low standby power consumption, less than 9W*3 Phase without neutral elinates the risk of high neutral currents*3 Phase active power factor correction technology, reduces the harmonic interference to the grid* Dual DSP design, provides the full digital control, less componets means higher reliability*Wide input voltage range, 260-530Vac, allows oparation in most poor grid conditions*Wide operating temperature range, -40°C~+75°C -
CCS type1 Combo 1 Connector EV Charger DC Fast Charging 150Amp Sae J1772 Plug
Product Model:MIDA-CSS1-EV150P,MIDA-CSS1-EV200P
Rated Current:150A/200A
Operated Voltage:DC1000V
Withstand Voltage:3200V
Waterproof Degree:IP65
Certification:CE ApprovedMechanical properties1. Mechanical life : no-load plug in/pull out>10000 times2. Impat of external force: can afford 1m drop and 2t vehicle run over pressureElectrical Performance1. Rated current:80A 125A 200A2. Operation voltage: 1000V DC3. Insulation resistance:>2000MΩ(DC1000V)4. Terminal temperature rise:<50K5. Withstand Voltage:3200V6. Contact Resistance: 0.5mΩ MaxApplied Materials1. Case Material: Thermoplastic,flame retardant grade UL94 V-02. Contact bush:Copper alloy,silver platingEnvironmental IEC performance1. Operating temperature: -30°C~+50°C -
Type1 plug 80A J1772 With 5m AC fast charging cable
Quick Details
- Type:
-
Plug
- Place of Origin:
-
Shanghai,China
- Model Number:
-
Type 1 EV Plug
- Brand Name:
-
DUOSIDA
- Product Name:
-
80A J1772 Type1 EV Plug
- Current Rate:
-
80A
- Working Voltage:
-
250V AC
- Withstand Voltage:
-
2000V
- Contact Impedance:
-
0.5M Max
- Terminal temperature Rise:
-
<50K
- Working Temperature:
-
-30C~+ 50C
- Waterproof:
-
IP55
- Vibration Resistance:
-
Meet JDQ 53.3 Requirements
- Certifications:
-
Rated Current:80AOperating VoltageAC 250VInsulation Resisitance>1000MΩ(DC500V)Withstand Voltage2000VContact PinCopper alloy, Silver platingWorking temperature-30°C ~+50°CFlame Retardant GradeUL94 V-0Contact Resistance0.5mΩ MaxWaterproofIP65CertificateCE, TUV ApprovedProduct Name
16A 32A Type 1 J1772 Inlet Socket for Electric
-
30KW High Efficiency Electric Vehicle DC Fast Charging Station Use EV Charger Power Module
OverviewQuick Details- Place of Origin:
-
China
- Model Number:
-
DCM1000100
- Type:
-
DC/AC Inverters
- Output Type:
-
TRIPLE, Multiple
- Output Current:
-
60A
- Output Frequency:
-
50/60Hz
- Size:
-
455*300*94MM(D*W*H)
- Weight:
-
17KG
- Certificate:
-
CE
- Product name:
-
30kW Power Module
- Power Supply:
-
3P+PE
- Rated Voltage:
-
260~470V AC
- Max. Input Current:
-
60A
- Input Frequency:
-
50/60Hz
- Standby Power:
-
<8W
- Rated Power:
-
30kW
- Enclosure:
-
Aluminized Zinc plate (SGLCC)
- LED Indicator:
-
Green/Yellow/Red
- Configuration:
-
Manual/Auto
-
30KW High Efficiency DC Fast Charging Station Use EV Charger Power Module
OverviewQuick Details- Place of Origin:
-
China
- Model Number:
-
DCM1000100
- Type:
-
DC/AC Inverters
- Output Type:
-
TRIPLE, Multiple
- Output Current:
-
60A
- Output Frequency:
-
50/60Hz
- Size:
-
455*300*94MM(D*W*H)
- Weight:
-
17KG
- Certificate:
-
CE
- Product name:
-
30kW Power Module
- Power Supply:
-
3P+PE
- Rated Voltage:
-
260~470V AC
- Max. Input Current:
-
60A
- Input Frequency:
-
50/60Hz
- Standby Power:
-
<8W
- Rated Power:
-
30kW
- Enclosure:
-
Aluminized Zinc plate (SGLCC)
- LED Indicator:
-
Green/Yellow/Red
- Configuration:
-
Manual/Auto
-
EV cord reel spring retractable cable reel for ev charger cable
Roll compact EV cord reel spring retractable cable reel electric automatic ev charging reel drum box
vehicle charging reel is suitable for single phase electrical connections and is delivered ready fitted with cables, plugs & mounting bracket as shown.JARCH Charging reel adapts flexibly to all operating conditions. In the private and commercial sector as well as for the supply of entire vehicle fleets in the commercial vehicle sector and public service. Depending on the application, plug types, cables as well as the overall design of our charging reels vary. With regard to the application, the cable and plug can be supplied sidewise, from the ceiling or from below. The corresponding cable length is controlled by our charging reel. This allows a very variable spatial positioning to the charging location of the vehicle. Our charging reel is the ideal supply for individual vehicles or vehicle fleets
-
CCS1 plug 80A 125A 200A With 5m DC fast ev car electric vehicle charging cable
Product Model:MIDA-CSS1-EV150P,MIDA-CSS1-EV200P
Rated Current:150A/200A
Operated Voltage:DC1000V
Withstand Voltage:3200V
Waterproof Degree:IP65
Certification:CE ApprovedMechanical properties1. Mechanical life : no-load plug in/pull out>10000 times2. Impat of external force: can afford 1m drop and 2t vehicle run over pressureElectrical Performance1. Rated current:80A 125A 200A2. Operation voltage: 1000V DC3. Insulation resistance:>2000MΩ(DC1000V)4. Terminal temperature rise:<50K5. Withstand Voltage:3200V6. Contact Resistance: 0.5mΩ MaxApplied Materials1. Case Material: Thermoplastic,flame retardant grade UL94 V-02. Contact bush:Copper alloy,silver platingEnvironmental IEC performance1. Operating temperature: -30°C~+50°C -
200A EV Fast Charger CCS Inlet IEC62196 Electric Vehicle DC Charging Socket With 1m Cable
Product Model:MIDA-CSS2-EV150S,MIDA-CSS2-EV200S
Rated Current:150A/200A
Operated Voltage:DC1000V
Withstand Voltage:3200V
Waterproof Degree:IP55
Certification:CE ApprovedPlug typeCCS combo 2Input power200AApplication standardIEC62196-3Plug shell materialThermoplastic (flame retardant grade: UL94-0)Operational temperature-30 °C to +50 °CVandalism-proofNoUV resistantYesCertificateCE, TUVCable length5m or customizedTerminal materialCopper alloy, silver platingTerminal temperature rise＜50kWithstand voltage3200VContact resistance≤0.5mΩMechanical life＞10000 times of off-load plug in/outCoupled insertion forceBetween 45N and 100NWithstandable impactDropping from a 1m height and running-over by a 2-ton vehicleWarranty2 years -
200A ev charger connector ccs combo 2 type 2 dc fast charging cable
Product Model:MIDA-CSS2-EV150P,MIDA-CSS2-EV200P
Rated Current:150A/200A
Operated Voltage:DC1000V
Withstand Voltage:3200V
Waterproof Degree:IP55
Certification:TUV,CE Approved -
Iec 62196 -2 Type 2 Ev Charging Socket Side Electric Electromagnetic Lock
Quick Details
- Type:
-
Plug
- Place of Origin:
-
China
- Product name:
-
EV Charging Socket Lock
- Current:
-
3A max
- Voltage:
-
DC 12V
- Applicable standard:
-
IEC 62196-2 Type 2
- IP Protection:
-
IP 54
- Operating Temperature:
-
-30℃ to + 60℃
- Contact bush:
-
copper alloy, silver plating
- Terminal temperature rise:
-
<50k
- Contact resistance:
-
<0.5mΩ
- Withstand voltage:
-
2000V
