Type 2 Holster Wall Holder for Europe Connector EV Charger

Short Description:

Product Name:Type 2 Holster Wall  Holder for Europe Connector EV Charger




Product Detail

FAQ

Product Tags

Type 2 Wall Holster3 Type 2 Wall Holster 6Waterproof
IP54
Certificate
CE, TUV Approved
Rated Current:
32A
Operating Voltage
AC 250V
Insulation Resisitance
>1000MΩ(DC500V)
Withstand Voltage
3200V
Contact Pin
Copper alloy, Silver plating
Working temperature
-30°C ~+50°C
Flame Retardant Grade
UL94 V-0

Features

1.Conform to the provisions and requirements of  IEC 62752,  IEC 61851.
2.Using riveting pressure process with none screw ,have a beautiful appearance. Hand-held design conform to the ergonomic principle , plug conveniently.
3.TPE for cable insulation prolonging the aging resistance  life-span, TPE sheath improved the bending life and wear resistance of ev charging cable.
4.Excellent protection performance, protection grade achieved IP67 (working condition).

Materials
Shell Material: Thermo Plastic ( Insulator inflammability UL94 VO)
Contact Pin: Copper alloy, silver or nickel plating
Sealing gasket: rubber or silicon rubber

TPE insulation,TPE Sheath EV Charging Cable for EV Plug & EV Socket ,32A 240V 62196
